Sprinter Model Bev Minibus
| verall Specification | ||
| Dimensions（LxWxH)(mm) | 5980×2010×2650 | |
| Wheelbase(mm) | 3665 | |
| Driving | left&Right Hand Drive | |
| Front/Rear Tread(mm) | 1720/1716 | |
| Front/Rear Overhang(mm) | 1030/1285 | |
| Max.Speed(km/h) | 100 | |
| Approach/Departure Angle（°） | 21/17 | |
| Minimum Ground Clearance（Full Load）（mm） | 180 | |
| Minimum Turning Radius（m） | 6.5 | |
| Curb Weight（kg） | 2990 | |
| Gross Vehicle Weight | 4490 | |
| Tire Type | 215/75R16LT 12PR | |
| Range Mileage （Full Load） | 300km | |
| Seats | 18+2(Co-drive)+1(Drive) | |
| Chassis Specification | ||
| Driving Type | R | |
| Drive Motor Rated/Peak Power（Kw） | 60/100 | |
| Drive Motor Rated/Peak Torque（N.m） | 310/700 | |
| Drive Motor Rated/Peak Speed（rpm） | 1850/4800 | |
| Drive Motor Cooling Mode | Liquid Cooling | |
| Drive Motor IP Grade | IP67 | |
| Drive Motor Rated Voltage | 384v | |
| Drive Motor Working System | S9 | |
| Motor Controller Rated/Peak Capacity(KVA) | 60/100 | |
| Motor controller Sustained/Transitory Current（A） | 180/420 | |
| Motor Controller Cooling Mode | 液冷 | |
| Motor Controller IP Grade | IP67 | |
| Motor Controller Rated Voltage | 360 | |
| Motor Controller Working System | S9 | |
| Battery Type | lithium iron phosphate | |
| Battery Capacity | 100.96 | |
| Brake System （Front/Rear） |
Disc/Drum， Vacuum assisted double circuit brake system; |
|
| ABS+EBD | ● | |
| Suspension System |
Front:Transverse single spring independent suspension; Rear:Longitudinal leaf spring type non-independent suspension |
|
| Steering System | hydraulic power assisted | |
| DC Fast Charge | 0.5C-1C | |
| AC slow charge | CCS2 European Standard Socket | |
| Standard Specifications | ||
| 3.1 | Exterior | |
| Integral Combination Headlights | ● | |
| Front Grille | ● | |
| Electrically Adjust Exterior Mirrors | ● | |
| Uv Protection Front Windshield | ● | |
| Front-row Electric Lift Glass | ● | |
| Rear Compartment Closed Blind Metal Windows | ● | |
| Intermittent Wipers | ● | |
| External Antenna | ● | |
| Steel Ring (including decorative cover) | ● | |
| Metallic paint (meteorite black) + Customer custom logo | ● | |
| 3.2 | Interior | |
| Beige Interior | ● | |
| Non-woven ceiling (flocking) | ● | |
| driving Seat Sun Visor | ● | |
| ABS Decorative Plate | ● | |
| Quartz Sand Floor Leather | ● | |
| Front-row Curtain | ● | |
| Adjustable Steering Wheel | ● | |
| Baggage Holder | ● | |
| 3.3 | Seats | |
| Fabric Seat | ● | |
| Sliding Front-row Seats | ● | |
| Three-point Safety Belt | ● | |
| Front-row Seat Detachable Headrest | ● | |
| 3.4 | Electric System | |
| Front Rear Combined Headlight | ● | |
| High Stop Lamp | ● | |
| Front Reading Light | ● | |
| Side Marker Light and Reflex Reflector | ● | |
| Loudspeaker | ● | |
| MP5 Multimedia and Rear View Camera | ● | |
| Manual Lock | ● | |
| Cigar Lighter | ● | |
| Overhead Air Conditioning | ● | |
| 3.5 | Special Equipment | |
| Basic Tool | ● | |
| Spare Tire | ● | |
| Optional Specifications | ||
| Optional body color and exterior trim | ||
| Metallic Paint | ● | |
| Customer custom logo | ⊙ | |
| Rear Stationary pedal | ● | |
| Sliding door in left side | ● | |
|
|
|
|
