Serial number
|
Project
|
Right Rudder
|
|
Standard
|
|
Vehicle parameters
|
Long * wide * highmm
|
Bus：5100×1715×2035
|
|
Wheelbase mm
|
3050
|
|
Wheel spacing mm
|
1435/1435
|
|
Quality of equipment kg
|
1660
|
|
Total mass kg
|
2500
|
|
Number of seats (person)
|
11\14
|
|
Maximum speed km/h
|
90
|
|
System architecture
|
|
|
Body form
|
Load-bearing body
|
|
|
Drive form
|
Rear rear wheel drive
|
|
|
Permanent Magnet synchronous motor
|
Rated Power 35kw peak power 70kw
|
|
|
kwhLithium iron phosphate battery capacity kwh
|
41.86
|
|
|
Front suspension form
|
Mcpherson independent suspension
|
|
|
Rear suspension form
|
5 leaf spring type non-independent suspension
|
|
|
Brake
|
Front disc rear drum, mechanical parking brake
|
|
|
Form of steering
|
Electric power steering
|
|
External configuration
|
|
|
Tires
|
185R14LT 8PR
|
|
|
Rims
|
Silver Steel Rim (optional black steel tire)
|
|
|
Front/rear bumper
|
Same color bumper
|
|
|
Front combination headlights
|
Standard configuration
|
|
|
Front fog lamp
|
Yes
|
|
|
Side turn signal
|
Fender, white shade, yellow bulb
|
|
|
Wipers
|
ont wiper (with frame)
|
|
|
External rearview mirror
|
Standard, matte black, external electric adjustment
|
|
|
Full glass
|
Dark Green (left and right rear glass window center window)
|
|
|
Glass elevator
|
Front door electric
|
|
|
Rear combination lamp
|
Double inverted, double fog headlights, integrated rear combination headlights
|
|
|
High position brake lamp
|
Yes
|
|
|
Reflective logo
|
Yes
|
|
Internal configuration
|
|
|
Sun Visor
|
Double Sun Visor, no makeup mirror
|
|
|
Inside Mirror
|
The Eye of the beholder
|
|
|
Audio-visual system
|
A tape recorder
|
|
|
Speaker
|
Two
|
|
|
Front defroster
|
Yes
|
|
|
The steering wheel is adjustable
|
None
|
|
|
Shift control
|
Spiral
|
|
|
Hand brake
|
Mechanical arm brake
|
|
|
Conditioning A/C
|
Single cold
|
|
|
Seat integrity
|
|
|
|
Front seat
|
|
|
|
Front seat belt
|
Three points
|
|
Security configuration, intelligence
|
|
|
airbag
|
None
|
|
|
Anti-lock Braking System (abebd)
|
Yes
|
|
|
Pedestrian alert system
|
Yes
|
|
|
Parking sensors
|
Yes
|
|
|
Reverse image
|
Yes
|
|
|
Control
|
Four-door central control
|
